RAYTUM

 Photonics

Turn-key Fiber Coupled Diode Laser

​

Item NumberDESCRIPTIONFiber   TypePrice(US$)
Qlite-405-30Single mode fiber coupled laser source, 405 nm, 30.0 mW, 1nm spectral widthS405-XP3700.00
Qlite-405-300Multi- mode fiber coupled laser source, 405 nm, 300 mW,Multi-mode3100.00
Qlite-450-10Single mode fiber coupled laser source, 450 nm, 10.0 mW, 1 nm spectral widthS405-XP3100.00
Qlite-488-20Single mode fiber coupled laser source, 488 nm, 20.0 mW, 1 nm spectral width
S405-XP3360.00
Qlite-505-10Single mode fiber coupled laser source, 505 nm, 10.0 mW, 1 nm spectral width
SM6003310.00
Qlite-520-10Single mode fiber coupled laser source, 520 nm, 10.0 mW, 1 nm spectral width
SM6003050.00
PLS-633-40Single mode fiber coupled laser source, 633 nm, 40.0 mW, 1 nm spectral width
SM600
3470.00
PLS-633-30-FBGSingle mode fiber coupled laser source, 633 nm, 30.0 mW, Frequency locked, 500kHz spectral width
SM600
3570.00
PLS-700-20Single mode fiber coupled laser source, 700 nm, 20.0 mW, 1 nm spectral width
SM600
4130.00
PLS-730-20Single mode fiber coupled laser source, 730 nm, 20.0 mW, 1 nm spectral width
SM600
4130.00
PLS-760-200Single mode fiber coupled laser source, 760 nm, 200.0 mW, 0.2 nm spectral width
HI-7803650.00
PLS-780-100Single mode fiber coupled laser source, 780 nm, 100.0 mW, 1.5 nm spectral width
HI-780
3010.00
PLS-785-250Single mode fiber coupled laser source, 785 nm, 250.0 mW, 1 nm spectral width
HI-780
3400.00
PLS-795-100-FBGSingle mode fiber coupled laser source, 795 nm, 100.0 mW, 0.2 nm spectral width
HI-780
3860.00
PLS-808-100Single mode fiber coupled laser source, 808 nm, 100.0 mW, 1 nm spectral widthHI-7802900.00
PLS-808-250Single mode fiber coupled laser source, 808 nm, 250.0 mW, 1 nm spectral widthHI-7803340.00
PLS-808-250-FBGSingle mode fiber coupled laser source, 808 nm, 250.0 mW, FBG locked, 0.2 nm spectral widthHI-7804100.00
PLS-830-100Single mode fiber coupled laser source, 830 nm, 100.0 mW, 2 nm spectral widthHI-7803650.00
PLS-850-100Single mode fiber coupled laser source, 850 nm, 100.0 mW, 1 nm spectral widthHI-780
2800.00
PLS-850-200Single mode fiber coupled laser source, 850 nm, 200.0 mW, 1 nm spectral widthHI-7803200.00
PLS-850-100-FBGSingle mode fiber coupled laser source, 850 nm, 100.0 mW, FBG Locked, 0.2 nm spectral widthHI-7804500.00
PLS-850-200-FBGSingle mode fiber coupled laser source, 850 nm, 200.0 mW, FBG Locked, 0.2 nm spectral widthHI-7804900.00
PLS-850-100Single mode fiber coupled laser source, 850 nm, 100.0 mW, 1 nm spectral widthHI-7803500.00
PLS-905-200Single mode fiber coupled laser source, 905 nm, 200.0 mW, 2 nm spectral widthHI-7803100.00
PLS-915-300Single mode fiber coupled laser source, 915 nm, 300.0 mW, 2 nm spectral widthHI-7803460.00
PLS-935-200Single mode fiber coupled laser source, 935 nm, 200.0 mW, FBG Locked, 1 nm spectral widthHI-7803150.00
PLS-940-100Single mode fiber coupled laser source, 940 nm, 100.0 mW, 1 nm spectral widthHI-7803700.00
PLS-940-100-FBGSingle mode fiber coupled laser source, 940 nm, 100.0 mW, FBG Locked, 0.2 nm spectral widthHI-7803970.00
PLS-940-200-FBGSingle mode fiber coupled laser source, 940 nm, 200.0 mW, FBG Locked, 0.2 nm spectral widthHI-7803630.00
PLS-980-100Single mode fiber coupled laser source, 980 nm, 100.0 mW,  2.5nm spectral widthHI-10603100.00
PLS-980-100-FBGSingle mode fiber coupled laser source, 980 nm, 100.0 mW, FBG locked, 0.3 nm spectral widthHI-1060
3130.00
PLS-980-500-FBGSingle mode fiber coupled laser source, 980 nm, 500.0 mW, FBG locked, 0.5 nm spectral widthHI-1060
3600.00
PLS-980-750-FBGSingle mode fiber coupled laser source, 980 nm, 750.0 mW, FBG locked, 0.5 nm spectral widthHI-10603400.00
PLS-1060-50-DFBSingle mode fiber coupled laser source, 1060 nm, 50.0 mW, 3MHz spectral widthHI-10606530.00
PLS-1060-400-FBGSingle mode fiber coupled laser source, 1060 nm, 400.0 mW, FBG locked,0.1 nm spectral widthHI-10605530.00
PLS-1030-400Single mode fiber coupled laser source, 1030 nm, 400.0 mW, 2 nm spectral widthHI-10603760.00
PLS-1030-1200Single mode fiber coupled laser source, 1030 nm, 1200.0 mW, 1 nm spectral widthHI-10604200.00
PLS-1030-50-DFBSingle mode fiber coupled laser source, 1030 nm, 50.0 mW, 3MHz spectral widthHI-10604200.00
PLS-1030-100-FBGSingle mode fiber coupled laser source, 1030 nm, 100.0 mW, FBG locked, 0.3 nm spectral widthHI-10603700.00
PLS-1030-400-FBGSingle mode fiber coupled laser source, 1030 nm, 400.0 mW, FBG locked, 0.1 nm spectral widthHI-10604100.00
PLS-1060-50Single mode fiber coupled laser source, 1060 nm, 50.0 mW, 2 nm spectral widthHI-10603300.00
PLS-1060-200Single mode fiber coupled laser source, 1060 nm, 200.0 mW, 3 nm spectral widthHI-10603100.00
PLS-1060-450Single mode fiber coupled laser source, 1060 nm, 450.0 mW, FBG locked, 4 nm spectral widthHI-10603200.00
PLS-1060-10-FBGSingle mode fiber coupled laser source, 1060 nm, 10.0 mW, FBG locked, 500kHz spectral width
HI-1060
3100.00
PLS-1060-20-FBGSingle mode fiber coupled laser source, 1060 nm, 20.0 mW, FBG locked, 500kHz spectral width
HI-1060
3120.00
PLS-1060-100-FBGSingle mode fiber coupled laser source, 1060 nm, 100.0 mW, FBG locked, 0.3 nm spectral width
HI-1060
3020.00
PLS-1060-150-FBGSingle mode fiber coupled laser source, 1060 nm, 150.0 mW, FBG locked, 0.3 nm spectral width
HI-1060
3200.00
PLS-1060-200-FBGSingle mode fiber coupled laser source, 1060 nm, 200.0 mW, FBG locked, 0.3 nm spectral width
HI-1060
3200.00
PLS-1064-600Single mode fiber coupled laser source, 1064 nm, 600.0 mW, 4 nm spectral width
HI-1060
3500.00
PLS-1064-1200Single mode fiber coupled laser source, 1064 nm, 1200.0 mW, 1 nm spectral widthHI-1060
3700.00
PLS-1064-50-DFBSingle mode fiber coupled laser source, 1064 nm, 50.0 mW, 3MHz spectral width
HI-1060
4170.00
PLS-1064-150-DBRSingle mode fiber coupled laser source, 1064 nm, 150.0 mW, 3MHz spectral width
HI-1060
5560.00
PLS-1064-400-FBGSingle mode fiber coupled laser source, 1064 nm, 400.0 mW, FBG locked, 0.1nm spectral width
HI-1060
3500.00
PLS-1080-600Single mode fiber coupled laser source, 1080 nm, 600.0 mW, 4nm spectral width
HI-1060
4100.00
PLS-1080-50-DFBSingle mode fiber coupled laser source, 1080 nm, 50.0 mW, 3MHz spectral width
HI-1060
6500.00
PLS-1080-400-FBGSingle mode fiber coupled laser source, 1080 nm, 400.0 mW, FBG locked, 0.1 nm spectral width
HI-1060
4120.00
PLS-1122-400-FBGSingle mode fiber coupled laser source, 1122 nm, 400.0 mW, FBG locked, 0.1 nm spectral width
HI-1060
5400.00
PLS-1150-300-FBGSingle mode fiber coupled laser source, 1150 nm, 400.0 mW, FBG locked, 0.1 nm spectral width
HI-1060
5500.00
PLS-1155-300Single mode fiber coupled laser source, 1155 nm, 300.0 mW, 6 nm spectral width
HI-1060
4570.00
PLS-1177-350Single mode fiber coupled laser source, 1177 nm, 350.0 mW, 10 nm spectral width
HI-1060
4500.00
PLS-1177-350-FBGSingle mode fiber coupled laser source, 1177 nm, 350.0 mW, FBG locked, 0.1 nm spectral width
HI-1060
5500.00
PLS-1240-350Single mode fiber coupled laser source, 1240 nm, 350.0 mW, 10 nm spectral width
HI-1060
4600.00
PLS-1240-500Single mode fiber coupled laser source, 1240 nm, 500.0 mW, 10 nm spectral width
HI-1060
5400.00
PLS-1240-350-FBGSingle mode fiber coupled laser source, 1240 nm, 350.0 mW, FBG locked, 0.1 nm spectral width
HI-1060
5520.00
PLS-1300-150Single mode fiber coupled laser source, 1300 nm, 150.0 mW, 7 nm spectral width
SM283100.00
PLS-1300-300Single mode fiber coupled laser source, 1300 nm, 300.0 mW, 6 nm spectral width
SM28
4600.00
PLS-1300-20-DFBSingle mode fiber coupled laser source, 1300 nm, 20.0 mW, 0.02 nm spectral width
SM28
3700.00
PLS-1300-50-DFBSingle mode fiber coupled laser source, 1300 nm, 50.0 mW, 3MHz spectral width
SM28
4300.00
PLS-1300-350-FBGSingle mode fiber coupled laser source, 1300 nm, 350.0 mW, FBG locked, 0.15nm spectral width
SM28
5500.00
PLS-1320-20-DFBSingle mode fiber coupled laser source, 1320 nm, 20.0 mW, 0.01nm spectral width
SM28
3700.00
PLS-1340-20-DFBSingle mode fiber coupled laser source, 1340 nm, 20.0 mW, 0.01nm spectral width
SM28
3700.00
PLS-1390-10-DFBSingle mode fiber coupled laser source, 1392 nm, 10.0 mW, 10MHz spectral width
SM28
3900.00
PLS-1420-150Single mode fiber coupled laser source, 1420 nm, 150.0 mW, 3nm spectral width
SM28
3680.00
PLS-1440-150Single mode fiber coupled laser source, 1440 nm, 150.0 mW, 3nm spectral width
SM28
3700.00
PLS-1450-200Single mode fiber coupled laser source, 1450 nm, 200.0 mW, 3nm spectral width
SM28
3900.00
PLS-1460-150Single mode fiber coupled laser source, 1460 nm, 150.0 mW, 3nm spectral width
SM28
3700.00
PLS-1460-350Single mode fiber coupled laser source, 1460 nm, 350.0 mW, 3nm spectral width
SM28
3500.00
PLS-1470-150Single mode fiber coupled laser source, 1470 nm, 150.0 mW, 3nm spectral width
SM28
3700.00
PLS-1480-300Single mode fiber coupled laser source, 1480 nm, 300.0 mW, 1.5 nm spectral width
SM28
3210.00
PLS-1480-500Single mode fiber coupled laser source, 1480 nm, 500.0 mW, 3nm spectral width
SM28
3800.00
PLS-1490-150Single mode fiber coupled laser source, 1490 nm, 150.0 mW, 3nm spectral width
SM28
3700.00
PLS-1490-20-DFBSingle mode fiber coupled laser source, 1490 nm, 20.0 mW, 0.01nm spectral width
SM28
3600.00
PLS-1508-5-DFBSingle mode fiber coupled laser source, 1508 nm, 5.0 mW, 5MHz spectral width
SM28
3120.00
PLS-1530-20-DFBSingle mode fiber coupled laser source, 1530 nm, 20.0 mW, 10MHz spectral width
SM28
3700.00
PLS-1550-150Single mode fiber coupled laser source, 1550 nm, 150.0 mW, 7 nm spectral widthSM28
3100.00
PLS-1550-5-DFBSingle mode fiber coupled laser source, 1550 nm, 5.0 mW, 2MHz spectral width
SM28
3100.00
PLS-1550-20-DFBSingle mode fiber coupled laser source, 1550 nm, 20.0 mW, 10 MHz spectral width
SM28
3500.00
PLS-1550-45-DFBSingle mode fiber coupled laser source, 1550 nm, 45.0 mW, 1 MHz spectral width
SM28
3400.00
PLS-1550-100-DFB-KSingle mode fiber coupled laser source, 1550 nm, 100.0 mW, 100kHz spectral width
SM28
4700.00
PLS-1550-100-DFB-MSingle mode fiber coupled laser source, 1550 nm, 100.0 mW, 1 MHz spectral width
SM28
4200.00
PLS-1550-10-FBGSingle mode fiber coupled laser source, 1550 nm, 10.0 mW, 500 kHz spectral width
SM28
4300.00
PLS-1570-10-DFBSingle mode fiber coupled laser source, 1570 nm, 10.0 mW, 10 MHz spectral width
SM28
3700.00
PLS-1580-20-DFBSingle mode fiber coupled laser source, 1580 nm, 10.0 mW, 10 MHz spectral width
SM28
3900.00
PLS-1600-20-DFBSingle mode fiber coupled laser source, 1600 nm, 20.0 mW, 10 MHz spectral width
SM28
3900.00
PLS-1650-5-DFBSingle mode fiber coupled laser source, 1650 nm, 10.0 mW, 2 MHz spectral width
SM28
3500.00
PLS-1650-3-FBGSingle mode fiber coupled laser source, 1650 nm, 3.0 mW, 500 kHz spectral width
SM28
4350.00
PLS-1940-15Single mode fiber coupled laser source, 1940 nm, 15.0 mW, 15 nm spectral width
SM20005240.00
PLS-2000-15Single mode fiber coupled laser source, 2000 nm, 15.0 mW, 15 nm spectral width
SM20005750.00

​Raytum Photonics

Q-Light-PLS series features:


  • Turn-key system
  • Fiber coupled
  • provide wavelength from UV-2000 nm
  • Extremely stable



Email:    yimin.hu@raytum-photonics.com

Phone:   703 8317809
